TSS-23HLN-D+

Monolithic Amplifier Die

50Ω 30 MHz to 2 GHz

• Medium power, +28.5 dBm typ.

• High IP3, 42.6 dBm typ. at 1 GHz

• Gain, 21.8 dB typ. at 1 GHz

• Low noise figure, 1.4 dB at 1 GHz

• Shutdown feature

• Operates over wide DC input: +3V to 8V

SCN-2-10+

Power Splitter/Combiner

2 Way-0° 50Ω 600 to 1000 MHz

• Industry leading combination of size/power handling

• Isolation resistor, external 100 ohms

• Low insertion loss, 0.5 dB typ.

• High isolation, 15 dB typ.

• Small size, 0.12”X0.06”X0.035”

• ESD non-sensitive

• Temperature stable LTCC technology

• Wrap around terminations for excellent solderability

• Low cost

NCS1-521+

RF Transformer

50Ω 223 to 520 MHz 1:1 Ratio

• Wideband, 223 to 520 MHz

• Low phase unbalance, 5 deg. and amplitude unbalance, 0.7 dB typ.

• Miniature size, 0.079”x0.049”x0.033”

• LTCC construction

• Low cost

• Aqueous washable

NCS4-521+

RF Transformer

50Ω 223 to 520 MHz 1:4 Ratio

• Wideband, 223 to 520 MHz

• Low phase unbalance, 5 deg. and amplitude unbalance, 0.7 dB typ.

• Miniature size, 0.079”x0.049”x0.033”

• LTCC construction

• Low cost

• Aqueous washable

SYTX2-451-5W+

RF Transformer

50Ω 5 Watt 10 to 450 MHz

• Low insertion loss, 0.5 dB

• Small size, 0.43 x 0.69 x 0.42”

• Balanced outputs

• Good amplitude and phase unbalances

• DC isolated

• High power input, 5 Watt max.

• Wide bandwidth, 440 MHz

• Good amplitude unbalance, 0.2 dB typ. at 1 dB bandwidth

• Excellent phase unbalance 7 deg. typ. at 1 dB bandwidth

Z7550-BMBF+

Matching Transformer

50/75Ω DC to 3000 MHz

• 2W Power Handling

• BNC-F (50W) to BNC-M (75W) Connectors

• Low loss (0.6 dB typ.) matching device

• Wide band coverage, DC-3000 MHz

• Connectorized package
