SFR-SM50+

Adapter SMA-Female to SMA-Male

50Ω DC to 18 GHz

• Ultra-wideband, DC-18 GHz

• Low insertion loss, 0.14 dB typ. up to 18 GHz

• Excellent VSWR, 1.12:1 typ. up to 18 GHz

• Low insertion loss, 0.14 dB typ. up to 18 GHz

• Excellent VSWR, 1.12:1 typ. up to 18 GHz

• Low cost adapters, available from stock

• Brass alloy and gold-plated berillium copper center connector

WVBP-64-WR15+

Bandpass Filter

59.4 to 61.6 GHz

• Precision Machining and Plating

• Outstanding Return Loss

• Super-High Rejection & Fast Roll-Off

• Low insertion loss, 0.8 dB typ.

• Excellent return loss, 26 dB typ.

WVBP-583-WR15+

Bandpass Filter

57.2 to 59.4 GHz

• Precision Machining and Plating

• Outstanding Return Loss

• Super-High Rejection & Fast Roll-Off

• Low insertion loss, 0.7 dB typ.

• Excellent return loss, 26 dB typ.

WVBP-633-WR15+

Bandpass Filter

61.5 to 63.8 GHz

• Precision Machining and Plating

• Outstanding Return Loss

• Super-High Rejection & Fast Roll-Off

• Low insertion loss, 0.9 dB typ.

• Excellent return loss, 26 dB typ.

WVBP-653-WR15+

Bandpass Filter

63.7 to 65.9 GHz

• Precision Machining and Plating

• Outstanding Return Loss

• Super-High Rejection & Fast Roll-Off

• Low insertion loss, 0.8 dB typ.

• Excellent return loss, 25 dB typ.
