ZPUL-30P+

Pulse Amplifier

50Ω Non-Inverting 0.0025 to 700 MHz

• High gain, 35 dB typ. with excellent flatness, ±0.6 dB typ.

• Can handle wide pulses with (15μs typ.) with excellent rise/fall time (1.1 ns typ.)

• Delay time, 1.5 ns typ.

• Protected by US Patent, 6,943,629

• Wide bandwidth 2.5 kHz to 700 MHz, useable to 1000 MHz

ZFL-272VH+

Broadband Amplifier

50Ω 0.03 to 2.7 GHz

• High IP3, 47dBm typ. at 1GHz

• Gain, 17dB typ. at 1GHz

• High Pout, P1dB 30dBm typ. at 1GHz

• Internally regulated DC and reverse voltage protected

SYBDC-10-13HP+

Bi-Directional Coupler

50Ω 10 dB Coupling 50 to 1000 MHz 10 Watt

• High power handling, 10W

• Full decade bandwidth

• Low mainline loss, 0.95 dB

• High directivity, 20 dB

• Excellent VSWR, 1.20:1

• Wideband frequency, 50-1000 MHz

• Flat coupling, ±0.2 Db

RDC-7-182-75X+

Directional Coupler

75Ω 7dB 5 to 1800 MHz

• Low mainline loss, 2.0 dB typ. at 1218 MHz

• Good Return Loss, 18 dB

• Excellent coupling flatness, ±0.3 dB

• Supports DOCSIS® 3.1 Systems

• Wideband, 5-1800 MHz

• Aqueous washable

EQY-2-24-D+

Gain Equalizer Die

50Ω 2dB DC to 20 GHz

• Excellent Return Loss, 20dB typ.

• Wide bandwidth, DC - 20 GHz

• 2.1 dB Slope

Quantity, Package                                              Model No.

Small, Gel - Pak: 5,10,50,100 KGD*                  EQY-2-24-DG+

Medium†, Partial wafer: KGD*<1620                EQY-2-24-DP+

EQY-5-24-D+

Gain Equalizer Die

50Ω DC to 20 GHz

• Excellent Return Loss, 20dB typ.

• Wide bandwidth, DC - 20 GHz

• 4.9 dB Slope

Quantity, Package                                             Model No.

Small, Gel - Pak: 5,10,50,100 KGD*                 EQY-5-24-DG+

Medium†, Partial wafer: KGD*<1710               EQY-5-24-DP+
