TSS-13LN+
Monolithic Amplifier
50Ω 1MHz to 1 GHz
• Ultra-High IP3, +39.2 dBm typ.
• Low supply voltage, 3 to 5V
• Excellent Noise Figure, 1.1 dB typ.
• Shutdown feature
• Gain, 22.8 dB typ. at 0.5 GHz
TSS-13HLN+
Monolithic Amplifier
50Ω 1MHz to 1 GHz
• Ultra-High IP3, +42.9 dBm typ.
• Medium power, +28.4 dBm typ.
• Excellent Noise Figure, 1.4 dB typ.
• Shutdown feature
• Gain, 23 dB typ. at 0.5 GHz
TSS-23LN+
Monolithic Amplifier
50Ω 30MHz to 2 GHz
• Ultra-High IP3, +36.4 dBm typ.
• Low supply voltage, 3 to 5V
• Excellent Noise Figure, 1.2 dB typ.
• Shutdown feature
• Gain, 21.5 dB typ. at 1 GHz
TSS-23HLN+
Monolithic Amplifier
50Ω 30MHz to 2 GHz
• Ultra-High IP3, +42.6 dBm typ.
• Medium power, +28.5 dBm typ.
• Excellent Noise Figure, 1.4 dB typ.
• Shutdown feature
• Gain, 21.8 dB typ. at 1 GHz
• High P1dB, 28.5 dBm at 1 GHz
ZCDC13-5R263-S+
Directional Coupler
50Ω 13dB Up to 20W 0.5 to 26.5 GHz
• Power Handling up to 20W
• Wide frequency range, 0.5 to 26.5 GHz
• Good coupling flatness, ±0.8 dB typ.
• Good directivity, 16 dB typ. up to 26.5 GHz
• Good return loss 22 dB typ. up to 26.5 GHz
• DC current pass through input to output
ZCDC16-5R263-S+
Directional Coupler
50Ω 16dB Up to 20W 0.5 to 26.5 GHz
• Excellent Coupling Flatness, ±0.9 dB typ.
• Power Handling up to 20W
• Wide frequency range, 0.5 to 26.5 GHz
• Good directivity, 16 dB typ. up to 26.5 GHz
• Good return loss 19 dB typ. up to 26.5 GHz
• DC current pass through input to output
ZCDC13-K26344+
Directional Coupler
50Ω 13dB Up to 20W 26.5 to 40 GHz
• Excellent Coupling Flatness, ±0.3 dB typ.
• Power Handling up to 20W
• Wide frequency range, 26.5 to 40 GHz
• Good directivity, 13 dB typ. up to 40 GHz
• Good return loss, 13 dB typ. up to 40 GHz
• DC current pass through input to output
ZCDC16-K0144+
Directional Coupler
50Ω 16dB Up to 19W 1 to 40 GHz
• Excellent Coupling Flatness, ±0.7 dB typ.
• Power Handling up to 19W
• Wide frequency range, 1 to 40 GHz
• Good directivity, 16 dB typ. up to 40 GHz
• Good return loss, 19 dB typ. up to 40 GHz
• DC current pass through input to output
ZCDC16-01263-S+
Directional Coupler
50Ω 16dB Up to 20W 1 to 26.5 GHz
• Excellent Coupling Flatness, ±0.6 dB typ.
• Power Handling up to 20W
• Wide frequency range, 1 to 26.5 GHz
• Good directivity, 14 dB typ. up to 26.5 GHz
• Good return loss, 20 dB typ. up to 26.5 GHz
• DC current pass through input to output
